Description

Although compact at 3 inch by 3-inch housing, don’t be fooled by its size. The Squadron-R Pro IR from Baja Designs comes in 850nm and is more powerful than most larger lights on the market today. While compact in size the Squadron-R Pro IR is equipped with our round bezel and a sleek black gloss aluminum housing that outshines the competition through both appearance and performance. This light is perfect for covert applications such as military, hunting, or where stealth is needed during the night while using night vision goggles, or NODs. Our 30-Day Satisfaction Guarantee and Limited Lifetime Warranty is included for the ultimate in purchase protection. USPTO Reg No. 5,766,659

NOTE: This light does not come with a wiring harness. The applicable wiring harness for this light is 640117.

Satisfaction Guarantee – 30-Day Money Back Guarantee

Limited Lifetime Warranty – Complete Purchase Protection

uService – Replaceable Lenses and Optics

ClearView – All the Light, Right Where You Need It

MoistureBlock – Waterproof, Rain Proof, Submersible

CopperDrive – Safely Driving LEDs at 100%

INFRARED (IR) LIGHTING

Sometimes, you need to see others without being seen. For those who like to maintain a low profile, Baja Designs has a great selection of infrared LED off-road lights and laser lights designed to fit your specific make and model of vehicle. Our infrared or IR automotive lights are based on the same technology used in night-vision goggles and other nighttime optical devices. Using IR lighting allows drivers to see what’s ahead without shining a beacon from their vehicle, making them less visible to those they don’t want to be seen by. Whether you need an IR hunting light, infrared security lighting, or a general off-roading light, we have the right solution for your needs, all backed by a limited lifetime warranty.

Military Lighting for Vehicles

Infrared lighting is sometimes referred to as military lighting because it’s mainly used in operations where being stealthy is important. The Baja Designs team has adapted several of our industry-leading LED auxiliary lights for use as automotive infrared lights, giving you the upper hand in critical situations. Our Infrared lights are compact and  will help you spot wildlife and intruders covertly. It comes with a mounting bracket to install like a regular aux light. (Please note that this fixture must be used in tandem with night vision goggles.)

Night Vision Task Light

If you need a high-power infrared light, the Baja Designs Infrared Squadron Pro series is up to the task. Driving/combo IR lights are available in 850nm or 940nm outputs and infrared-LED work lights are available in 850nm output. These military-grade lights are the official IR lights of the Polaris MRZR and Dagor vehicles used by the U.S. armed forces and they’re available for civilian use. The IR Follow Me Light is another option for when you need more directional versatility.

No matter what your needs are, Baja Designs has the right driving lights for every situation. Our off-road infrared lighting solutions are designed to be easy to install and to deliver the performance you want at a price you can appreciate. Browse our selection today and order your favorite vehicle-mounted IR lights.

Baja Designs 597073 Installation Sheet

Dimensions

Depth (in.)	2.76
Height (in.)	3.07
Length (in.)	3.07
Weight (lbs.)	0.75

Specifications

Amperage Rating (A)	1.73
Average Rated Life (hr.)	49,930
Beam Pattern	Driving/Combo
Bezel Material	Billet Machined Aluminum
Description	Round; Driving/Combo; IR 850nm
Housing Color	Black
Housing Material	Aircraft Grade Aluminum with Mil-Spec Hard Anodize
Lens Color	Infrared
Lens Material	Hardcoated Polycarbonate
Light Quantity	1
Lighting Modes	High (1800mW)
Lighting Quantity	4
Lighting Technology	Osram 850nm LED
Lighting Type	Forward Projecting
Mounting Hardware Included	Yes
Mounting Hardware Material	Stainless Steel
Overvoltage Protection	Built-In
Product Type	Squadron-R Pro Infrared LED Light Pod
Wattage (W)	24
Wiring Harness Included	No

Standards & Compliance

Standards/Compliance (Durability)	Exceeds MIL-STD810G (Mil-Spec Testing)
Standards/Compliance (Impact Resistance)	IK10 Compliant (Mechanical Impact Testing)
Standards/Compliance (Water Resistance)	IP69K (Waterproof up to 9ft & Pressure Washable)
