Rockford Fosgate RM110D2B 10″ Dual 2-Ohm Car Subwoofer – High-Power, Compact Design

Description

The RM110D2B is a black 10” subwoofer designed with weatherproofing technology specific for use in marine watercraft or powersports applications. It features a color molded grille that is 100% UV stable. This model can be used in sealed, vented or infinite baffle installations.

FEATURES AT A GLANCE

• 2-Year Warranty
• Proprietary corrosion resistant spring loaded push terminals
• UV and Salt-Fog Resistant Santoprene surround
• 100% UV stable ASA injection molded plastic parts
• Ultra-flexible fully insulated silicone lead wire
• Moisture, tear and fatigue resistant Aramid fiber spider
• Removable trim ring/grille
• True Marine Grade compliance
• Injection molded mineral filled polypropylene cone body with UV inhibitors
• Available in black

Klippel Verified

Klippel is a speaker certification program allowing us to deliver the best possible subwoofers.

ASTM Test Standards

Marine Grade standards ensure resistance to extreme environments.

CEA-2031

Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards.

Element Ready™ | Subwoofers

All components are protected against harsh outdoor elements like Dust, UV, Temperature, Water, Corrosion & Vibration.

FlexFit 2 Basket – Marine Sub

The slot mounted frame pattern allows for variable adjustments to the mounting position of the subwoofer.

VAST Surround – Marine

Patent: Patent Pending

The Vertical Attach Surround Technique significantly increases a subwoofer’s effective radiating cone area up to 25%.

Anodized Aluminum Voice Coil Former

Rockford Fosgate subwoofers use anodized aluminum voice coil formers for superior heat dissipation (up to 100° at full power levels).

Nominal ImpedanceDual 2-OhmVoice Coil TypeDual Voice CoilSd (cm²)394Le (mH)2.17Re (Ohms)3.7Xmax (mm)7.0CEA-2031 CompliantPower Handling (Watts RMS)200 Watts RMS
400 Watts MaxQts0.47Vas (Liters)50.2Woofer Displacement0.10 cu. ft. (2.80 Liters)Qes0.50Cutout Diameter8.95 in. (227 mm)Speaker ConnectorDual 12 AWG compressionMounting Depth4.4 in. (112 mm)Voice Coil Diameter2″ aluminumShipping Weight10.25 Lbs. (4.6 Kg.)SPL (dB @ 1w/1m)89Qms8.18Fs (Hz)33.5Size10″Magnet Weight (oz)

39.75 oz. (1.13 Kg)

Available Wiring Diagrams

Please consult your amplifier owner’s manual for lowest recommended impedance.

Wiring Diagram #1

Wiring Diagram #2

Wiring Diagram #3

Wiring Diagram #4

Wiring Diagram #5

Wiring Diagram #6

Wiring Diagram #7

Wiring Diagram #8

Wiring Diagram #9
