Description
Designed from the ground up our new S1 fills the shoes of a large light in a small package! The S1 utilizes a highly specialized reflector and LED combination to put 2,320 raw lumens down range. With the 2.1 inch length, width, and height, the S1 is highly versatile for any application that is in need of light. This version has a white-coated finish that is perfect for marine applications. Whether you’re looking for a light to drive off of, or something to light up a campsite the S1 will exceed your expectations! US Patent Number 11273751.
ELS™ Scores:
S1 Spot Clear: ELS 72⁰/ 6.1/ 155’/ 1927
Note: Single lights do not come with wiring harness. Add our Squadron/S1/S2 2-pin Harness (640117) to your order if you need a harness.
Satisfaction Guarantee – 30-Day Money Back Guarantee
Limited Lifetime Warranty – Complete Purchase Protection
uService – Replaceable Lenses And Optics
ClearView – All The Light, Right Where You Need It
MoistureBlock – Waterproof, Rain Proof, Submersible
CopperDrive – Only LED Driven At 100 Percent
5000K Daylight – Less Driver Fatigue, Natural Color
Baja Designs 380001WT Installation Sheet
Baja Designs 380005WT Installation Sheet
Baja Designs 380006WT Installation Sheet
| Housing Material | Hard Anodized and Powder Coated Cast Aluminum |
| Lens Color | Clear |
| Lens Material | Hardcoated Polycarbonate |
| Light Quantity | 1 |
| Lighting Modes | Beam |
| Lighting Quantity | 1 |
| Lighting Technology | LED |
| Lighting Type | Forward Projecting |
| Mounting Hardware Included | Yes |
| Mounting Hardware Material | Stainless Steel |
| Overvoltage Protection | Built-In |
| Product Type | S1 LED Light Pod |
| Voltage | 9-28 |
| Wattage (W) | 19.596 |
| Wiring Harness Included | No |
| Amperage Rating (A) | 1.420 |
| Average Rated Life (hr.) | 49,930 |
| Beam Pattern | Spot |
| Bezel Material | Powder Coated Cast Aluminum |
| Brightness (Lumens) | 2320 |
| Description | White Housing; Spot; Clear |
| Housing Color | White |
Standards & Compliance
| Standards/Compliance (Durability) | Exceeds MIL-STD810G (Mil-Spec Testing) |
| Standards/Compliance (Impact Resistance) | IK10 Compliant (Mechanical Impact Testing) |
| Standards/Compliance (Water Resistance) | IP69K (Waterproof up to 9ft & Pressure Washable) |
Dimensions
| Depth (in.) | 2.100 |
| Height (in.) | 2.100 |
| Length (in.) | 2.100 |
| Weight (lbs.) | 0.400 |
MEET THE S1 – Big Light, Small package
Performance Per Inch
Compact in size, the S1 is packed with the same race-winning DNA as our flagship series lights. The S1 delivers big performance in a small package. Take an inside look at what makes the S1 the most versatile and powerful compact light in our lineup—built by the Scientists of Lighting.
2,320 Powerful Lumens
We took the DNA out of our XL80, scaled it down to a single high-output 20-watt LED and paired with our Clearview® optics allows the S1 to deliver an impressive 2,320 lumens that projects light into zones 1, 2, and 4 for optimal trail coverage. That means you get performance normally reserved for larger lights—now in a form factor that fits anywhere and bright enough to be used as a standalone driving light.
uSERVICE® Technology
Customize and maintain your Baja Designs S1 LED Light with ease using our exclusive uService® technology. Whether you’re replacing a damaged lens or fine-tuning your beam pattern, the S1 LED Light offers unmatched serviceability and flexibility. With the ability to easily swap optics, you can tailor your lighting setup to match any off-road adventure or riding condition. Make the most of your Baja Designs S1 with a lighting solution that’s built for performance, durability, and total customization.
